Imperial Productions®
Doric Smooth
Columns
Load
Bearing and
Decorative
Split
for Post Wrap
Tapered
and Non Tapered
Doric
Smooth Standard Sizes
Select Heights and Diameter for Prices |
|
|
|
Design Theory:
Doric Column Origins |
The Doric Order of
Columns is one of the three main Classical Greek orders of columns:
Doric, Ionic and Corinthian. Doric uses an Attic Base however Greek
Doric has no base.
Imperial Productions®
offers Doric columns with Tapered or
Non-Tapered
stylus or shafts. The shafts can be Fluted or Smooth. Tapered
shafts may have the correct taper or entasis (ie Taper 2/3rds down the
stylus from the top. The last third is straight ending at the Attic Base
which is used on all orders except Tuscan.
Imperial Productions®
offers Doric columns both load bearing and decorative to wrap a load
bearing posts or stand alone engaged against a wall to enhance a
building's facade. Add columns to legitimize any modern building.
Doric Load Bearing
Columns support the Entablature of a Classical or Modern structure.
Larger diameters can support up to 20,000 lbs without internal supports.
Decorative Doric
columns can stand alone as a whole column or be specified to be split.
Split Doric columns can be engaged or placed against a solid wall or
specified to be split-to-wrap a load bearing steel or wood post.
Imperial Productions®
has a vast selection of Doric Columns for commercial, residential, movie,
garden and theatre applications.
|
Source:
Definitions by
Vitruvius Pollio
1st Centrury BC |
click to
Enlarge
the PDF
|
Standard
Capitals and Bases sold separately |
|
|
|
Material
Summary
Hardwoods
Hand Crafted
All parts can
be customized
|
Interior Paint Only: Finger Joint Pine
Interior Stain & Paint: American Poplar, Alder, Ash,
Basswood,
Beech,
Birch Cherry,
Maple, Maple (Sap), Mahogany-African,
Oak
(Red), Oak (White), Walnut
Exterior (Stain & Paint)
White Pine, Knotty Pine, Clear Pine, Western Red Cedar
Made in
5 Parts
Whole
Shafts or Split for Pilaster & Post Wrap
Custom
Heights with the correct enthasis
|
Fiberglass
Interior /
Exterior use
Made from
Molds |
Interior
& Exterior Composite
Gelcoat,
polyester resin and glass fibers. Lite weight 2-3lbs per square
foot.
Weather resistant for earthquakes and hurricane zones.
Meets
ASTM-E84 fire rating.
Water
resistant for fountains and water displays.
Mold 2
pieces, Bondo to cover seam, no customization, cut to height
|
PolyCompTM
Interior /
Exterior use
Made from
Molds
|
Load
Bearing Composite Columns
70%
calcium carbonate, 5% marble chips, 25% Polyester Resins
Meets
ASTM-E84 fire rated.
Order whole
or split for Post Wrap / Pilaster.
No
customization, cut to height, cut to height.
Post Wrap may
involve modification of your load bearing posts
or
removal of tabs by others
|
ZeamentTM
Interior /
Exterior use
Made from
Molds
|
Exterior
Composite Columns
Lite weight
Portland cement, sand, alkali
resistant fibers aggregates,
polymer
adhesive and water. Smooth
internally pigmented 12 colors
Sandblasted for Stone Look, Hurricane,
earthquake zone.
Can be submerged
in water Meets ASTM-E84 Fire rating
Odorless and
emission free safe for indoor
use.
Made with natural
raw materials can experience light variations
in color and texture.
Molded in 2 parts
Seam remains
as a reveal.
|
StoneMoldTM
Interior use
Made from
Molds
|
Interior
Composite Columns
Molded stone: Alpha
gypsum, pigment, aggregates
water and polymers.
Looks like natural stone. Weight 2-5 lbs /
Foot. Sealed with
clear finish.
Made with natural
raw materials and may experience slight variation in
color and texture.
Molded in 2
parts
seam remains as
a reveal.
|
